The Series CCT40/50 Current Transformers are a low cost alternative for measuring power and monitoring the operation of fans, pumps, or other equipment. For use on existing installations, split core models can be installed without disconnecting cables. Each model offers three jumper selectable ranges and a choice of three different outputs.

Product Applications

• BAS
• HVAC

Features

• Integral mounting flange for quick installation
• Solid core or split core configurations
• Jumper selectable range

Specifications

• Solid or Split Core, Field Selectable Range

• Amperage Range: Field selectable; up to 200 A (depending on model).

• Output: 0-5 V, 0-10 V, or 4-20 mA (depending on model).

• Power Requirements: Self-powered or 15-42 VDC loop powered (depending on model).

• Accuracy: 1%.

• Temperature Limits: -22 to 158°F (-30 to 70°C).

• Humidity Limits: 0 to 95% (non-condensing).

• Response Time: 250 ms to 90%.

• Isolation Voltage: 2000 V.

• Frequency: 10 to 400 Hz.
